Description

The EFT E616P 6-Axis Agricultural Drone Frame with 10L Capacitive Tank is designed for agricultural spraying, crop protection, fertilizer application, and precision farming operations. Built using advanced engineering materials, the frame provides a strong and durable structure capable of operating in challenging agricultural environments.

The integrated 10-liter capacitive tank is suitable for pesticide, herbicide, fungicide, and liquid fertilizer applications. Its 6-axis configuration offers enhanced flight stability and payload management, making it suitable for professional agricultural UAV operations.

The frame supports large 28-32 inch propellers and is compatible with X8 and 8118 motors, 80A FOC ESCs, and 12S power systems. With a maximum take-off weight of 36kg, it can accommodate spraying systems and agricultural payloads required for large-scale farming operations.

Its folding structure allows easier transportation and storage, while the modular design simplifies assembly, maintenance, and field servicing. The EFT E616P is suitable for precision agriculture projects where reliability, payload capacity, and operational efficiency are essential.

Features:

• 6-axis agricultural drone frame design
• Integrated 10L capacitive tank
• Constructed from advanced engineering materials
• Strong and durable frame structure
• Lightweight design for agricultural UAV applications
• Folding frame for easy transport and storage
• Easy assembly and disassembly
• Compatible with 28-32 inch propellers
• Supports X8 and 8118 motor configurations
• Compatible with 80A FOC ESCs
• Supports 12S power systems
• Maximum take-off weight of 36kg
• Designed for agricultural spraying operations
• Suitable for precision farming applications
• Excellent structural strength for demanding field conditions

Applications and Use Cases:

• Precision pesticide spraying in agricultural fields
• Liquid fertilizer application across farms and plantations
• Herbicide spraying in orchards and vineyards
• Fungicide application for crop protection programs
• Precision agriculture and crop management
• Nursery and greenhouse spraying operations
• Large-area agricultural maintenance
• Farm spraying in areas inaccessible to ground vehicles

How to Use EFT E616P 6-Axis Agricultural Drone Frame with 10L Capacitive Tank:
Begin by assembling the six-axis arms onto the main frame and securing the 10L capacitive tank using the mounting system. Install compatible motors, ESCs, flight controller, and spraying equipment. Attach 28-32 inch propellers and connect the 12S power system. Connect the spraying system tubing, calibrate the spray nozzles, verify payload balance, and complete a pre-flight inspection before operating the UAV for agricultural spraying missions.

Note:

• Actual product color may vary depending on supplier availability.
• Product images are for reference purposes only.

Package Includes:

• 1 × EFT E616P 6-Axis Agricultural Drone Frame
• 1 × 10L Capacitive Tank
